OUR PRODUCTS
- Compact design.
- High operating efficiency resulting in lower power consumption
- High reliability.
- Easy to service and install
- Dynamically balanced rotating parts including rotor and impeller ensures minimum vibration and longer life
- Back pull-out design for easy servicing and repair
- Mechanical seal is provided as per customers requirement.
- Silent Operation
- Full stainless steel design.
- Booster sets for domestic water supply.
- Automatic starts / stops when equipped with press control or pressure tank.
| Head | Upto 50m |
| Discharge | Upto 60 LPM |
| Power Rating | Upto 1 Hp/ 0.75 Kw |
| Voltage Range | Single phase 230 V, 50 Hz AC supply |
| Speed | 2900 RPM |
| Temperature | Upto 55°C |
| Motor Type | Capacitor run motor, TEFC type |
- Suitable for liquid transfer
- Small industrial water supply systems
- Washing systems
- HVAC
- Water treatment systems
- Industrial plants
- Boiler feed systems
- Pressure boosting systems
- Domestic water supply
- Horticultural irrigation systems
| Motor | |
| Motor Body | Cast iron / Aluminum |
| Rotor Shaft | Stainless Steel |
| Pump | |
| Pump Shaft | Stainless Steel |
| Diffuser | Stainless Steel / Cast Iron |
| Stage Casing | Stainless Steel |
| Impeller | Stainless Steel / Bronze |
| Sealing Arrangements | Mechanical Seal |
| Cover Dome | Cast Iron / Stainless Steel |
| Suction Bracket | Cast Iron / Stainless Steel |
| System Assembly | |
| Five Way Connector | Brass |
| Non Return Value | Brass |
| Pressure Tank | MS EXPOXY Coated with high grade Butyl Rubber |
| Pressure Switch | Fitted with single pole double throw switch |
| Pressure Gauge | Bourdon Type |
