OUR PRODUCTS
- High efficiency as of international standards, leading to energy saving
- Low operating cost
- Superior design material as well as manufacturing process assure longer life
- Silent, vibration-free running
- Fitted with Carbon Bushes
- Water lubricated motor with easily rewindable stator
- Rigid cast iron motor frame, impeller and volute casing
- Ultra modern design
- Easy installation
| Head | Upto 90m |
| Discharge | Upto 2500 LPM |
| Power Rating | Upto 30Hp/22Kw |
| No. Of Stages | 1 |
| Voltage Range | 220V-240V & 380V - 440V, AC Single phase & 3 phase , 50Hz |
| Speed | 2900 RPM |
| Motor Type | Water filled water cooled Induction motor |
| Max.Sand Contents | 50g/m3 |
| Temperature | 40°C |
| Motor Type | Water-filled and water cooled Induction motor |
- Rural and urban draining water installations
- Water supply to high-rise buildings
- Water circulating system for lawns & gardens
- Sprinkler and drip irrigation
- Industrial service water supply schemes
- Decorative water fountains
| Bush | Gun Metal |
| Oilseal | Rubber |
| Oilseal Guard | M S |
| Non Drive Housing | C I Casting |
| Motor Body | C I Casting |
| Winding Guard | P V C |
| Stator Stamping | M S Electrical Sheet |
| Bush Cover | M S |
| Cable Gromet | Rubber |
| Cable Guard | P V C |
| Screw | S S |
| Rotor M/C. | Copper / S S |
| Drive End Housing | C I Casting |
| Key | E N - 8 |
| Impeller | C I Casting / S.S |
| Nut | M S |
| Stud | M S |
| Chamber | C I Casting |
| Base Stand | M S Angle |
| Hex Pin | M S |
| Lifting Hook | M S |
| Gasket Packing | Rubber |
| Delivery Flange | C I Casting |
| Gasket Packing | Rubber |
| Suction Flange | C I Casting |
| P V C Connector | Plastic |
| Spring Washer | M S |
| Jali | S S |
| Stainer | C I Casting |
| Drain Plug | Gun Metal |
| O Ring | Rubber |
