- Water filled motor with easily rewindable stator
- More durability and hygiene
- Suitable for single phase 220 V and three phase 380 V, 50 Hz power supplies
- High operating efficiency
- Specially designed thrust bearing to withstand high axial thrust load
- Extremely hardwearing water lubricated bearing
- Energy efficient radial pumps
- Thread type motor construction ensures service feasibility
- Specially designed Deep Drawn type pump ensures perfect alignment and Thereby increases the life of the pump set
- Designed for wide voltage operation
- Best alternative for JET & Compressor pump set
- Additional intermediate bearing in higher stage pumps.
| Head | Upto 320m |
| Discharge | Upto 400 LPM |
| Power Rating | Upto 7.5Hp/5.5Kw |
| No. Of Stages | 60 |
| Voltage Range | 220V- 240V, AC Single phase , 50Hz 340V- 440V, AC Three phase , 50Hz |
| Speed | 2900 RPM |
| Motor Type | Water filled water cooled Induction motor |
| Max.Sand Contents | 50g/m3 |
| Temperature | 40°C |
- Irrigation systems for Agriculture including Drip and Sprinkler systems
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Industrial water supply
| Pump Bracket | Grey Iron |
| Pump Shaft | Stainless Steel |
| Diffuser | Grey Iron |
| Impeller | Stainless Steel |
| Diffuser Cover | Grey Iron |
| NRV Body | Grey Iron |
| Sand Slinger | Nitrile Rubber |
| Seal Housing | Grey Iron |
| Mechanical Seal | Carbon/ceramic Face |
| Upper Housing | Grey Iron |
| Rotor Shaft | Stainless Steel |
| Stator Body | Stainless Steel |
| End Ring | Carbon Steel |
| Lower Housing | Grey Iron |
| Thrust Bearing Base | Grey Iron |
| Motor Base | Grey Iron |
| Diaphragm | Nitrile Rubber |
| Fasteners | Stainless Steel |
